Pneumatic  Butterfly Valve

Pneumatic wafer butterfly valve, Brand econ, Size 2-56 inch (upper 56 inch will be ordered), Body material Cast iron/Stainless steel, Seat material: NBR/EPDM/PTFE, Actuator: ROPO of Germany

see more ...
Teflon Wafer Butterfly Valve

Wafer butterfly valve disc and seat PTFE, brand econ, size 2-56 inch (upper 56 inch will be ordered)

[(bold)|Design:]
The body is suitable for installation between flanges which their holes are as per the Standard of DIN EN 1092-2, ANSI CLASS 150 until 16 bar. In opening position the butterfly is located in the middle part completely and makes the best situation for passing the flow with the lowest drop pressure. The seat (Teflon) is located inside the body and in two sides and it’s changeable and makes the good sealing form each two sides. Lug model for using at the end of line is presentable.

[(bold)|Notice:]
These valves don’t need the gasket and using the sealing gasket will interrupt the valves operation. These valves are made for the special using which are resistant against the corrosion.

[(bold)|Using Cases:]
Medical, food, chemical, gasoline and acids.

[(bold)|Color of Body:]
Inside and outside of body is covered with powder by Electro Static.

[(bold)|Applicant Temperature:]
Theses valves are usable in 180˚C. In other cases like, kind, speed and temperature please contact with Paivand Sanat Energy Company.

[(bold)|Advantages:]
1- Less thickness which are as per the ISO 5752 series 20 or EN 558 series 20, Valves with low weight and dimensions which minimize the problems of installing, storage and transportation.
2- Installation in all positions like vertical, horizontal and slant is possible.
3- The sealing operation is in two sides.
4- They are useful for opening and cutting and also for controlling the flow with the lowest drop pressure.
5- The Gearbox and hand lever or pneumatic actuator is possible for company and also it’s changeable for customer.

see more ...
Cast Iron Check Valve

Dual plate check valve Econ of Netherland: model H77XR-16, these valves don’t need Gasket and using the sealing Gasket will interrupt the valves operation. Body Cast iron/Ductile iron and disc is SS316 , PN16 , Class 150 – Size 2” ~ 24”

see more ...
Seat Teflon Butterfly Valve

Wafer butterfly valve disc and seat PTFE, brand econ, size 2-56 inch (upper 56 inch will be ordered)

[(bold)|Design:]
The body is suitable for installation between flanges which their holes are as per the Standard of DIN EN 1092-2, ANSI CLASS 150 until 16 bar. In opening position the butterfly is located in the middle part completely and makes the best situation for passing the flow with the lowest drop pressure. The seat (Teflon) is located inside the body and in two sides and it’s changeable and makes the good sealing form each two sides. Lug model for using at the end of line is presentable.

[(bold)|Notice:]
These valves don’t need the gasket and using the sealing gasket will interrupt the valves operation. These valves are made for the special using which are resistant against the corrosion.

[(bold)|Using Cases:]
Medical, food, chemical, gasoline and acids.

[(bold)|Color of Body:]
Inside and outside of body is covered with powder by Electro Static.

[(bold)|Applicant Temperature:]
Theses valves are usable in 180˚C. In other cases like, kind, speed and temperature please contact with Paivand Sanat Energy Company.

[(bold)|Advantages:]
1- Less thickness which are as per the ISO 5752 series 20 or EN 558 series 20, Valves with low weight and dimensions which minimize the problems of installing, storage and transportation.
2- Installation in all positions like vertical, horizontal and slant is possible.
3- The sealing operation is in two sides.
4- They are useful for opening and cutting and also for controlling the flow with the lowest drop pressure.
5- The Gearbox and hand lever or pneumatic actuator is possible for company and also it’s changeable for customer.

see more ...
Steam Trap Screwed Ends

Steam Trap Screwed Ends Cast Iron and Stainless steel, Brand TL of Taiwan , Stainless steel 1/2-1 inch

see more ...
Stainless Steel Disc Check Valve

.Disc check valve wafer type stainless steel, Brand: Econ, Size 1- 10 inch .They are designed for installation between flanges. These valves are suitable for a wide range of fluids, hot water, steams and etc

see more ...
Bellows Sealed Globe Valve

Carbon Steel (GS-C25) Econ® bellow sealed globe valves, SS trim, pressure rating PN 16, straight and angle pattern, flanged ends acc. to DIN PN 16, outside screwed stem and non-rising hand wheel for opening and cutting flow. 1-chain wheel (if required, fitted with chain) 2- Stem extension (specify height when ordering) 3- Limit switch (es) 4- Balanced disc 5- Non-standard flange drilling

see more ...
Steam Trap Flanged Ends

Model TL-62, Cast iron steam trap flange ends, size 1.2” ~ 2” ,PN16

see more ...
Pressure Reducing Valve

Brass Pressure Reducing Valve Screwed ends, Brand: R.B.M of Italy, Size 1/2-4 inch, adjustable until 7 bar

see more ...
Brass Safety Valve With Lever

.Brass Safety Valve screwed ends lever type, Brand S.S of Taiwan, Size 1/2-2 inch , Working Temp.: -45 ˚C/+ 185˚C, Working Pressure: 0-10Bar, For Natural Gas, Air and Steam

see more ...
Stainless Steel Safety Valve

Stainless steel safety valve screwed ends, Brand S.S of Taiwan, Size: 1/2- 2 inch

see more ...
Stainless Steel Safety Valve With lever

Stainless steel safety valve screwed ends lever type, Brand S.S of Taiwan, Size: 1/2- 2 inch

see more ...
Steam Trap Ecrewed Ends

"TL-63: Steam Trap Screwed Ends ,Cast Iron, Size: 1/2"~2", TL-63SS:Steam Trap Screwed Ends, CF8M, PN40/ANSI 600LB , Size:1"~3/8

see more ...
Sight Glass Screwed Ends

Sight Glass screwed Ends Cast iron and Stainless steel, Brand TL of Taiwan, Size 1/2-2 inch

see more ...
Flanged Carbon Steel Check Valve

Flanged Carbon Steel Check Valve Brand: Econ Design: ASME B16.34,GB1223,API6D PN16 ~ PN40 , Class150 ~ 2500 Size: DN50 ~ DN900 , 2”~36”

see more ...
Flanged Carbon Steel Gate Valves

شیر کشویی فولادی فلنج دار مارک econ هلند: ازسایز "2 الی"36 Class150~2500, PN16~PN40

see more ...
Flanged Carbon Steel Globe Valve

Angle 90 globe valve Flange ends carbon steel (GS-C25), Brand econ, Size 1-14 inch, PN40

see more ...
 Dual Plated Check Valve

Cast Iron dual plated wafer check valve disc stainless steel, Brand econ, Size 2-24 inch

see more ...
Sight Glass Flanged Ends

Sight Glass Flanged Ends cast Iron /SS304 or SS316, Brand TL of Taiwan, Size: 1/2- 8 inch

see more ...
Flanged Sight Glass

Sight Glass Flanged Ends cast Iron /SS304 or SS316, Brand TL of Taiwan, Size: 1/2- 8 inch

see more ...
گروه شرکت های پیوند صنعت انرژی

Unit 401and 205, Floor 4, No .5,Third Alley, Koohe Noor St.,

Motahari Ave.,Tehran, IRAN,

Paivand Sanat Energy Company (PSE Co.) was founded on 2007 and since its establishment focused on supplying high quality products in oil, gas, petrochemical and HVAC industry. PSE with precious experience obtained during these years could hold a substantial position in the market which made PSE one of the leading companies in supplying required products and accessories especially industrial valves in oil, gas, petrochemical and steam industry.

PSE mission is to provide top quality products and services at the shortest time to meet customer’s demands. In order to fulfil the projects requirements, PSE established a fully equipped workshop with quality control and valve testing benches supported by qualified staff.

After Negotiating with well-known worldwide brands which all are reputable companies in the field of design, manufacture, supply and repair of manual and Control valves, PSE managed to obtain official representation of companies and factories which are in high level of quality, technology and price.

By having an experienced team of engineers and sales staff, PSE succeeded to be registered in several Iranian National vendor lists such as National Iranian Gas Company (N.I.G.C), Kala Naft and all other oil, gas and petrochemical refineries which are listed in following vendor registration table.

pict631800000001186245100001

گروه شرکت های پیوند صنعت انرژی

Categories link Energy Company

Manual Valves

Manual Valves

Different kinds of butterfly valves with lever, gearbox or pneumatic actuator with easy and fast operation for flow on-off and adjustment are available.

View Product List
Control valves

Control valves

These valves can be used to shut-off the flow. Also, they are suitable for temperature, output flow and pressure adjustment.

View Product List
Check valves ,strainer , Globe and gate valves

Check valves ,strainer , Globe and gate valves

Different kinds of globe valves, gate valves, check valves and strainers for oil, gas and petrochemical industry are available.

View Product List
Steam traps and sight Glass

Steam traps and sight Glass

Different kinds of steam trap, sight glass and humidity separator with ADCA Portugal and TL Taiwan are available.

View Product List
Solenoid Valves

Solenoid Valves

In 2 cases of on and off will control the flow. Wide range of Solenoid valves for steam, water, air, oil ,etc is applicable.

View Product List
Ball and shut-off valves

Ball and shut-off valves

Ball and shut-off valves are available with brand of Artec AIS GmbH.

View Product List
